Service Information
1-10
Item Specifications
Overall length 1,970mm
Overall width 700mm
Overall height 1,110mm
Dimensions Wheel base 1,350mm
Seat height 765mm
Ground clearance 130mm
Dry weight 110kg
Curb weight 240kg
Type Underbone
Front suspension/stroke Telescopic/97mm
Rear suspension/stroke Swing arm/74mm
Front tire size/type 120/70-13/Tubeless
Rear tire size/type 130/60-13/Tubeless
Tire Pressure 1 person Front 1.75kg/㎠(175kPa)
Rear 2.00kg/㎠(200kPa)
Frame 2 person Front 2.25kg/㎠ (225kPa)
Rear 2.25kg/㎠ (225kPa)
Front brake Hydraulic disk
Rear brake Drum brake
Fuel tank capacity Full capacity 7.5ℓ
Reserve capacity 1.2ℓ
Caster angle 25
○
Trail 84.7㎜
Front fork oil capacity 80㎤
Type Oil cooled/air cooled 4 cycle SOHC engine
Cylinders/Arrangement 1(Single cylinder), front angle 80
○
Bore and stroke 56 ×50.7 mm
Displacement 124.9㎤
Compression ratio 10.8 : 1
Valve train SOHC chain drive
Oil capacity 1.1ℓ After disassembly
0.75ℓ After Oil filter change
Engine 0.8ℓ After Oil change
0.9ℓ
After Oil change with Oil in the Oil hose removed
Lubrication system Forced pressure splash type
Air cleaner type Wet sump
Cylinder compression 13.8kg/㎠
Intake valve: Open 5
○
BTDC
Closed 14
○
ABDC
Exhaust valve: Closed 18
○
BBDC
Closed 1
○
ATDC
Valve clearance(cooling-off period)
intake 0.12 ± 0.02 ㎜
Exhaust 0.12 ± 0.02 ㎜
Specifications
