Service Information
1-11
Item Specifications
Type/Venturi bore CV type(vacuum)24.2mm
Model mark BDS 26 -112
Choke type Autoby-starter
Carburetor Main jet #95
Pilot screw initial setting 1 and 1/2 trust out
Float level 13 mm
Idle speed 1,800±100(rpm)
Clutch type Automatic Transmission
Drive Train Primary reduction 3.231(42/14)
Secondary reduction 2.786(39/14)
Ignition system C.D.I. lgnition
Ignition timing F mark 15
○
BTDC/1,800(rpm)
Full advance 19
○
AC generator capacity 125W/5,000(rpm)
Battery type/capacity Closed type (MF)12V 8AH
Spark plug CR8EH-9
Spark plug gap 0.8-0.9mm(0.031-0.035in)
Electrical Fuse capacity 15A
Systems starting system Kick/starter motor
Headlight(high/low) 12V 35/35W
Position light 12V 3.4W
Turn signal light(Fr/Rr) 12V 10W×4
Tail/stop light 12V 21 / 5W
High-beam indicator 12V 3.4W
Turn signal indicator 12V 3.4W×2
Speedometer lamp 1.7W×2
Trunk lamp 1.4W×1
