Lubrication
2-7
Radiator
Removal/Installation
● Remove the front wheel.
● Remove the front cover, front side cover and
inner box.
● Loosen the flange bolt(3EA), oil bolt and remove
the radiator from the main pipe bracket.
Radiator
Radiator bracket
Radiator collar
Flange bolt
bolts
Radiator
