Inspections/Adjustments
3-10
● Check the tread depth at the tire center.
● If the tread depth has reached the service limit,
replace the tire.
Service limit: 4mm (0.16in)
7.5mm (0.3in)
Steering Head Bearing
NOTE
● Lift the front wheel and check if the handle moves
right and left smoothly. If the handles move
heavily, check if the cable or electric cord
interferes with the handle. If the handle moves
satisfactorily, adjust the steering head bearing.
Check the cable if it interferes with the handle
operation.
Wear indicator position mark
Wheels/Tires
NOTE
Item Front wheel Rear wheel
Driver only 1.75(175) 2.00(200)
Driver and a passenger 2.25(225) 2.25(225)
Standard Pressure kg/
㎠㎠
(kPa)
Check the tire pressure when the tires have been
cooled off. Check the tread (the part making
contact with the road surface) and side for wear,
cracks or damage. Replace damaged tires.
Tire pressure gauge
To Next Page
