DAELIM NS125III User Manual

Generator/Starter Clutch
● Use a special socket to tighten the starter driven
gear with lock nuts.
Torque value: 9.0kg-m(90N.m, 65ft-lb)
Tool: Special socket (12.7
××
28
××
120)
● Assemble the washer.
● Assemble the R. crank case cover (⇨ 8-4)
● Assemble the A.C. generator. (⇨ 8-2)
● Assemble the shroud. (⇨ 8-2)
8-8
Starter clutch
Lock nut
