Pilot's Operating Handbook
Section 7
Description
Edition 0 - March 05, 2019
Rev. 3
Page 7.5.12
>> With HomeSafe emergency function (Post-MOD70-0650-34A)
Figure 7.5.5A (1/2) - Brake system
1) Reservoir
2) Vent
3) HomeSafe braking servo-actuator
4) HomeSafe master cylinder
5) R.H. station master cylinders
6) PARK BRAKE control knob
7) PARK BRAKE valve
8) Drain
9) Pilot's station master cylinders
10) L.H. brake assembly
11) R.H. brake assembly
