Pilot's Operating Handbook
Section 7
Description
Edition 0 - March 05, 2019
Rev. 3
Page 7.8.4
>> With HomeSafe emergency function (Post-MOD70-0650-34A)
Figure 7.8.1A (1/2) - Fuel system
1) Flow divider
2) Flowmeter
3) Collector tank
4) Fuel regulator
5) High pressure pump (HP)
6) Oil to fuel heater
7) Low pressure switch
8) Fuel jet
9) Main mechanical boostpump
10) Electric boost pump
11) Fuel filter
12) Filter clogging by-pass valve
13) Filter clogging indicator
14) Fuel unit
15) Filter drain
16) HomeSafe fuel shut-off valve
17) Fuel return pipe
18) Filling port
19) NACA scoop
20) Tank vent valve
21) Fuel level gages
22) Tank drain valve
23) Check-valve
24) Low level detector
25) Suction strainer
26) Fuel amplifier
27) Sequencer
