Pilot's Operating Handbook
Section 7
Description
Edition 0 - March 05, 2019
Rev. 1
Page 7.12.4
Figure 7.12.1 (1/2) - Air data system
1) Pitot L
2) Dynamic system drain
3) Electronic Standby Instrument
4) ADC
5) ADC
6) FWD pressure bulkhead
7) Static system drain
8) Static system drain
9) Static system drain
10) Emergency static system drain
11) Emergency static valve (Normal / alternate)
12) Instrument panel
13) Dynamic system drain
14) Pitot R
15) Rear pressure bulkhead
16) Static port
17) Emergency static port
18) Static port
