Daher TBM 940 - Page 934

Pilot's Operating Handbook
List of equipment
Edition 0 - March 05, 2019
Rev. 0
Page 30
S/
R/
A/
O
Ar
m
in.
(m)
Weight
per unit
lb
(kg)
Required (R) or Standard (S) or Optional (A or O)
equipment
Item
OPT70
or
MOD70
34-51 - NAV 1 installation
S VHF GS-NAV antenna DM N4-17N 3.307
(1.500)
401.57
(10.200)
S Receiver
(integrated in the MOD70-0564-31A GIA 64W
Integrated Avionics Unit # 1 : refer to ATA 34-28)
/ /
34-52 - NAV 2 installation
S Receiver
(integrated in the MOD70-0564-31A GIA 64W
Integrated Avionics Unit # 2 : refer to ATA 34-28)
/ /
34-53 - Transponder
A 0475-34D Transponder # 1 GTX 33D - Mode S with antenna
diversity and extended squitter
3.39
(1.54)
147.68
(3.751)
+ Antenna KA 61 (under fuselage) 0.40
(0.18)
150.08
(3.812)
+ Antenna KA 61 (above fuselage) 0.40
(0.18)
193.22
(4.908)
O 0542-34P Transponder # 2 GTX 345R - full Mode S enhanced
surveillance capability, without antenna diversity,
with extended squitter and ADS-B IN acquisition
(with ethernet connection)
2.90
(1.32)
147.20
(3.738)
+ Antenna KA 61 0.40
(0.18)
150.08
(3.812)
O 0542-34Q Transponder # 1 GTX 345R - full Mode S enhanced
surveillance capability, without antenna diversity,
with extended squitter and ADS-B IN acquisition
(with ethernet connection)
2.90
(1.32)
147.20
(3.738)
+ Antenna KA 61 0.40
(0.18)
150.08
(3.812)
PIM - DO NOT USE FOR FLIGHT OPERATIONS
