Page #15 background imageLoading...
Page #15 background image
Parameter
Note
Name
Enter user name, max of 16 characters, click to switch
language input, including letter, symbol and number.
FP1FP 3
Collect fingerprint, one user can max collect 3 FP (fingerprint). Each
fingerprint requires three times of verification. Please operate
according to audio prompt.
PWD
Enter password, password supports 18 digits of number.
Department
Click or to select preset department, see Ch 3.2.3.
Schedule Mode
Click or to select.
Personal shift, set single user shift, do not execute department
shift.
Department shift, execute department shift, execute attendance
following selected department linked shift.
See Ch 3.3.2. to set personal and department shift.
User Level
Click or to switch right.
User, only has attendance right.
Administrator, can login system, and set.
Chart 3-1
3.2.2 Edit User
You can search user in the system, modify and delete user info.
Select User> Edit User, click . If there is user info, it will show user info on screen,
see Figure 3-6.
Figure 3-6

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua Technology ASA1222E-S and is the answer not in the manual?

Dahua Technology ASA1222E-S Specifications

General IconGeneral
TypeBasic access control reader
CertificationCE, FCC
Product colorBlack
LED indicatorsStatus
Number of users1000 user(s)
Access code reader-
Fingerprint readerYes
Authentication typePassword
Keypad number of keys16
Fingerprint sensor typeOptical
Flash memory0.08 GB
Display typeTFT
Display diagonal2.4 \
Maximum resolution320 x 240 pixels
DC voltage range5 - 5 V
Power consumption1000 mA
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 95 %
Front cameraNo
Weight and Dimensions IconWeight and Dimensions
Depth120 mm
Width175 mm
Height23 mm
Weight350 g
