2 Device Installation
2.1 Checklist
No.
Name
Quantity
1
Unit
1
2
Power adaptor
1
3
Power line
1
4
Screw
Screw bag*1
Expansion bolt*3
5
Quick Start Guide
1
Chart 2-1
2.2 Panel and Port
Time Attendance Terminal appearance is shown in Figure 2-1 and Figure 2-2.
Figure 2-1
Icon
Note
09
Number key for input of number and letter
Back or exit
Up (attendance events switch)
Down (attendance events switch)
Enter or confirm
Backspace
Enter main menu or switch input
