3.2.1 Add User
You can add new user, as well as record new user info, including ID, name, fingerprint,
password and etc. A user can register for attendance by fingerprint and password. The
system supports up to 1000 users and 5 admin users.
Step 1. Select User>Add New User, click . See Figure 3-4 and Figure 3-5.
Figure 3-4
Figure 3-5
Step 2. Click or , select parameter. Click to confirm. Click number
key to enter info, and click again to save. See Chart 3-2.
Parameter
Note
ID
Enter user ID, max of 8 digits of number. You can click or
to select number.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua Technology ASA1222E-S and is the answer not in the manual?

Dahua Technology ASA1222E-S Specifications

General IconGeneral
TypeBasic access control reader
CertificationCE, FCC
Product colorBlack
LED indicatorsStatus
Number of users1000 user(s)
Access code reader-
Fingerprint readerYes
Authentication typePassword
Keypad number of keys16
Fingerprint sensor typeOptical
Flash memory0.08 GB
Display typeTFT
Display diagonal2.4 \
Maximum resolution320 x 240 pixels
DC voltage range5 - 5 V
Power consumption1000 mA
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 95 %
Front cameraNo
Weight and Dimensions IconWeight and Dimensions
Depth120 mm
Width175 mm
Height23 mm
Weight350 g
