Appendix 2 Text Input
The device support text input of English, number and symbol. Click to switch.
Number
Step 1. Click to switch input, see Figure A2-1.
Figure A2-1
Step 2. Enter number, click to confirm, see Figure A2-2.
Figure A2-2
English
Step 1. Click to switch to English, see Figure A2-3.
Figure A2-3
Step 2. Enter letter, enter corresponding letter, see Figure A2-4.
Figure A2-4
Step 3. Click .
Symbol
Step 1. Click to switch input, see Figure A2-5.
Figure A2-5

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua Technology ASA1222E-S and is the answer not in the manual?

Dahua Technology ASA1222E-S Specifications

General IconGeneral
TypeBasic access control reader
CertificationCE, FCC
Product colorBlack
LED indicatorsStatus
Number of users1000 user(s)
Access code reader-
Fingerprint readerYes
Authentication typePassword
Keypad number of keys16
Fingerprint sensor typeOptical
Flash memory0.08 GB
Display typeTFT
Display diagonal2.4 \
Maximum resolution320 x 240 pixels
DC voltage range5 - 5 V
Power consumption1000 mA
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 95 %
Front cameraNo
Weight and Dimensions IconWeight and Dimensions
Depth120 mm
Width175 mm
Height23 mm
Weight350 g
