Figure 3-25
3.7.4 Device Info
You can view device type, version and device no.
Select Sys Info>Device Info, click .
3.8 Attendance Operation
When you complete setup of user management and attendance shift, you can execute
attendance in standby interface.
Password attendance
Click number key, enter “user ID”, click , enter password. Click again to
complete.
FP attendance
In FP area, collect fingerprint, and then FP attendance is available.
3.9 Attendance Statistics
The following are some examples to illustrate attendance statistics rule.
Period 1
9:0012:00
Period 2
14:0017:30
Overtime Work
18:4520:00
Late Time
5 min
Early Leave
5 min
Chart 3-4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dahua Technology ASA1222E-S and is the answer not in the manual?

Dahua Technology ASA1222E-S Specifications

General IconGeneral
TypeBasic access control reader
CertificationCE, FCC
Product colorBlack
LED indicatorsStatus
Number of users1000 user(s)
Access code reader-
Fingerprint readerYes
Authentication typePassword
Keypad number of keys16
Fingerprint sensor typeOptical
Flash memory0.08 GB
Display typeTFT
Display diagonal2.4 \
Maximum resolution320 x 240 pixels
DC voltage range5 - 5 V
Power consumption1000 mA
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)5 - 95 %
Front cameraNo
Weight and Dimensions IconWeight and Dimensions
Depth120 mm
Width175 mm
Height23 mm
Weight350 g
