Dahua Technology ASA1222E-S User Manual

1. Select “Date Format”, click .
2. Click or to switch date format.
3. Click to confirm.
 Set device displayed date.
1. Select setup date, click .
2. Click or to select set position, click .
3. Click number key to set period or click or to adjust time, click
to confirm. Select next position to set.
4. Click . System asks if you want to save.
5. Click to save.
 Set device display time.
1. Select “Time Setup”, click .
2. Click or to select set position, click .
3. Click number key to set period or click or to adjust time, click
to confirm. Select next position to set.
4. Click . System asks if you want to save.
5. Click to save.
3.5.2 Communication
Communication setup includes IP address, Mask, and Gate way

Dahua Technology ASA1222E-S Specifications

General

Type	Basic access control reader
Certification	CE, FCC
Product color	Black
LED indicators	Status
Number of users	1000 user(s)
Access code reader	-
Fingerprint reader	Yes
Authentication type	Password
Keypad number of keys	16
Fingerprint sensor type	Optical
Flash memory	0.08 GB
Display type	TFT
Display diagonal	2.4 \
Maximum resolution	320 x 240 pixels
DC voltage range	5 - 5 V
Power consumption	1000 mA
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	5 - 95 %
Front camera	No

Weight and Dimensions

Depth	120 mm
Width	175 mm
Height	23 mm
Weight	350 g
