Dahua Technology DH-XVR1B04H User Manual

User’s Manual
134
Configure the settings for start IP address (the IP address is allocated in sequence), subnet
mask, default gateway, user name, and password.
Click OK to save the settings.
5.6.1.6 Exporting IP Address
You can export the added IP address to the USB storage device.
The exported information is saved in .csv file, which includes IP address, port number, channel
number, manufacturer, user name, and password.
Insert the USB storage device to the USB port of the Device.
Click Export.
Browse
Configure the save path.
Click OK to save the settings.
A pop-up message indicating "Successfully exported" is displayed.
Click OK.
When exporting IP address, the Backup Encryption check box is selected by default. The file
information includes IP address, port, channel number, manufacturer, user name, and password.
 If you select the Backup Encryption check box, the file format is .backup.
 If you clear the Backup Encryption check box, the file format is .csv. In this case, there might be
a risk of data leakage.
5.6.1.7 Importing IP Address
You can add remote devices by importing IP address information.

Dahua Technology DH-XVR1B04H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	8 channels
Multi-display modes	4, 8
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	1920×1080, 1280×1024, 1280×720
BNC input ports	8
BNC output ports	1
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search

Weight and Dimensions

Depth	192 mm
Width	197 mm
Height	41 mm
Weight	540 g
