Users Manual
154
Tag management
Be default, it manages all the tagged videos of the selected channel.
To search the tagged video, select channel number from the Channel list, enter time in Start Time
box and
End Time box, and then click Search.
All the tagged videos display in time order.
To modify the name of tagged video, double-click a tagged video, the Modify Tag dialog box is
displayed.
To delete the marked video, select the tagged video, and then click Delete.
After opening the Tag Management interface, the playback will pause until exiting this interface. If
the marked video that was in playing back is deleted, the playback will start from the first tagged
video in the Tag List.
5.9.6 Playing Back Snapshots
You can search and play back the snapshots.
Select Main Menu > SEARCH, the video search interface is displayed.
In the Search Type list, select Picture.
In the Channel list, select a channel number.
In the Calendar area, select a date.
Click .
The system starts playing snapshots according to the configured intervals.
5.9.7 Playing Back Splices
