Users Manual
25
Table 3-6 Front panel description
No.
Port Name
Function
1 Status indicator light Glows blue when the device is working properly.
2 USB port
Connects to the external devices such as keyboard, mouse, and
USB storage device.
3.1.8 DH-XVR7416L-4KL-X
Front panel
Table 3-7 Front panel description
No.
Port Name
Function
1 IR receiver Receives infrared signal from remote control.
2 USB port
Connects to peripheral devices such as USB storage device,
keyboard, and mouse.
3.1.9 DH-XVR7816S-4KL-X/DH-XVR7816S-4KL-X-LP
Front panel
Table 3-8 Front panel description
No.
Port Name
Function
1 IR receiver Receives infrared signal from remote control.
2 USB port
Connects to peripheral devices such as USB storage device,
keyboard, and mouse.
3.1.10 DH-XVR5432L-X/DH-XVR5408L-X/DH-XVR5416L-X
