Users Manual
6
Fix screws
2.2.2 DH-XVR7104E-4KL-X/DH-XVR7108E-4KL-X/DH-XVR7104E-4KL-
B-X/DH-XVR7108E-4KL-B-X
2.2.2.1 Installing Battery
The battery is only provided with some models.
Pull the battery cable through the hole.
Pull battery cable through hole
Connect the cable into the port.
