Users Manual
190
5.11.2.3 Playing the Detected Faces
On the displayed faces as shown in Figure 5-141, double-click on the face.
Record playback
Click to start playing the recorded detected face.
Click Back to exit the playing interface and return to the faces displaying interface.
5.11.3 Configuring IVS Function
The IVS function processes and analyzes the images to extract the key information to match with the
preset rules. When the detected behaviors match with the rules, the system activates alarms.
The IVS function and face detection function cannot be enabled at the same time.
5.11.3.1 Configuring Intelligent Settings
You can configure the intelligent settings for both analog cameras and IP cameras.
Not all models support this function.
Disable the expanded IP channels first before using this function for analog cameras.
Select Main Menu > SMART DETECTION > Parameters > IVS.
