Users Manual
166
White light
Configure the settings for the white light parameters.
Table 5-38 White light parameters
Parameter
Description
Channel
In the
Channel
list, select a channel that is connected to a white light
camera.
Delay
Set a length of time for the Device to delay turning off alarm after the
alarm is cancelled. The value ranges from 5 seconds to 30 seconds, and
the default value is 5 seconds.
Mode Set the alarm mode of white light to be
Always on
or
Flicker
.
Flicker Frequency
When setting the alarm mode of white light to be
Flash
, you can select
the flash frequency from
Low
,
Middle
, and
High
.
Click Apply to complete the settings.
5.10.3.3 Configuring Siren
When the motion detection alarm is activated, the system links the camera to generate sound alarm.
To use this function, connect at least one camera that supports audio function.
Select Main Menu > ALARM > Alarm-out Port > Siren.
