User’s Manual
246
Parameter
Description
Status
Indicates the status of UPnP function.
Offline: Failed.
Online: Succeeded.
LAN IP
Enter IP address of router on the LAN.
After mapping succeeded, the system obtains IP address automatically
without performing any configurations.
WAN IP
Enter IP address of router on the WAN.
After mapping succeeded, the system obtains IP address automatically
without performing any configurations.
Port Mapping List
The settings in PAT table correspond to the UPnP PAT table on the router.
Service Name: Name of network server.
Protocol: Type of protocol.
Int. Port: Internal port that is mapped on the Device.
Ext. Port: External port that is mapped on the router.
 To avoid the conflict, when setting the external port, try to use the
ports from 1024 through 5000 and avoid popular ports from 1
through 255 and system ports from 256 through 1023.
 When there are several devices in the LAN, reasonably arrange the
ports mapping to avoid mapping to the same external port.

When establishing a mapping relationship, ensure the mapping
ports are not occupied or limited.
 The internal and external ports of TCP and UDP must be the same
and cannot be modified.
 Click to modify the external port.
Click Apply to complete the settings.
In the browser, enter http://WAN IP: External IP port. You can visit the LAN Device.
5.15.1.9 Configuring SNMP Settings
Not all models support this function.
You can connect the Device with some software such as MIB Builder and MG-SOFT MIB Browser to
manage and control the Device from the software.
Preparation for Configuration
 Install the software that can manage and control the SNMP, such as MIB Builder and MG-SOFT MIB
Browser
 Obtain the MIB files that correspond to the current version from the technical support.

Dahua Technology DH-XVR1B04H Specifications

General

Aspect ratio	16:9
Certification	FCC: Part 15 Subpart B CE: CE-LVD: EN 60950-1/IEC 60950-1 CE-EMC: EN 61000-3-2, EN 61000-3-3, EN 55032, EN 50130, EN 55024 UL: UL 60950-1
Product color	Black
Rack capacity	1U
Playback modes	Fast, Next, Pause, Play, Previous, Repeat, Shuffle, Slow, Stop, Zoom
Backup function	Yes
Channels quantity	8 channels
Multi-display modes	4, 8
Video capturing speed	60 fps
Maximum recording time	1 h
Audio formats supported	AAC, G.711, PCM
Network connection type	RJ-45
Maximum video resolution	1920 x 1080 pixels
Video compression formats	H.264, H.264+, H.265, H.265+
Analog signal format system	NTSC, PAL
Video capturing speed (PAL)	30 fps
Playback resolutions supported	1920×1080, 1280×1024, 1280×720
BNC input ports	8
BNC output ports	1
USB 2.0 ports quantity	2
HDD interface	Serial ATA
Maximum HDD capacity	6000 GB
DC voltage	12 V
Power supply type	DC
Power consumption (typical)	10 W
Package weight	1000 g
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	-10 - 45 °C
Storage relative humidity (H-H)	0 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Number of users	128 user(s)
Ethernet interface type	Fast Ethernet
Supported network protocols	HTTP, HTTPS, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter , DDNS, FTP, Alarm Server, P2P, IP Search

Weight and Dimensions

Depth	192 mm
Width	197 mm
Height	41 mm
Weight	540 g
