Local Configurations 90
Figure 5-48
Configure the settings for the zero-channel parameters. See Table 5-17. Step 2
Enable zero-channel function.
In the Compression list, select the video compression standard
according to the device capability. The default is H.265.
In the Resolution list, select the video resolution. The default is
704×576 (D1).
Select a value between 1 and 25 for PAL standard, and between 1
and 30 for NTSC standard. The actual arrange is decided and
selected dependent on the Device capability.
The default value is 1024Kb/S. The actual arrange is decided and
selected dependent on the Device capability and frame rate.
Table 5-17
Click Apply to save the settings. Step 3
In the live interface on the web, click to select one of the
multi-channel modes, and then you can view the local video image.
5.2.6.4 Configuring TV
Not all models support this function.
