12Technicaldata
Installerreferenceguide
26
AZQS100~140B8V1B+AZQS100~140B7Y1B
Splitsystemairconditioners
4P3855291–2014.08
Multiplerowsofunits
Layout If Then(mm)
≥1000
≥200
≥2000
≥100
≥3000
≥600
≥1500
b
≥100
≥100
≥100
≥100
≥100
≥100
H
B
H
U
H
B
≤½H
U
b≥250
½H
U
<H
B
≤H
U
b≥300
H
B
>H
U
NOTallowed
Stackedunits(max.2levels)
If Then
Thereisdangerofdrainagedrippingandfreezingbetweentheupper
andlowerunits.
Installaroofbetweentheupperandlowerunits.
Installtheupperunithighenoughabovethelowerunittopreventice
buildupattheupperunit'sbottomplate.
A
≥500
≥1000
A
≥500
≥300
ARoof
Thereisnodangerofdrainagedrippingandfreezingbetweenthe
upperandlowerunits.
Itisnotrequiredtoinstallaroof,butsealthegapbetweentheupper
andlowerunitstopreventdischargedairfromflowingbacktothe
suctionsidethroughthebottomoftheunit.
≥100
≥300
B
≥100
≥1000
B
BSealedgap
