3 Aboutthebox
3.1 Overview:Aboutthebox
This chapter describes what you have to do after the box with the
outdoorunitisdeliveredonsite.
Itcontainsinformationabout:
▪ Unpackingandhandlingtheunits
▪ Removingtheaccessoriesfromtheunits
Keepthefollowinginmind:
▪ At delivery, the unit must be checked for damage. Any damage
mustbereportedimmediatelytothecarrier'sclaimsagent.
▪ Bringthepackedunitasclose as possible to its final installation
positiontopreventdamageduringtransport.
3.2 Outdoorunit
3.2.1 Tounpacktheoutdoorunit
21
3.2.2 Tohandletheoutdoorunit
Carrytheunitslowlyasshown:
CAUTION
Toavoidinjury,doNOTtouchtheairinletoraluminumfins
oftheunit.
3.2.3 Toremovetheaccessoriesfromthe
outdoorunit
1×
2
1
a
1×
b
1×
c
2×
d
1×
e
1×
ENERG
IJAY
IAIE
ENERG
IJAY
IAIE
a Generalsafetyprecautions
b Outdoorunitinstallationmanual
c Cabletie
d Fluorinatedgreenhousegaseslabel
e Energylabel
4 Abouttheunitsandoptions
4.1 Overview:Abouttheunitsand
options
Thischaptercontainsinformationabout:
▪ Identifyingtheoutdoorunit
▪ Combiningtheoutdoorunitwithoptions
4.2 Identification
NOTICE
Wheninstallingorservicingseveralunitsatthesametime,
make sure NOT to switch the service panels between
differentmodels.
4.2.1 Identificationlabel:Outdoorunit
Location
