12Technicaldata
Installerreferenceguide
28
AZQS100~140B8V1B+AZQS100~140B7Y1B
Splitsystemairconditioners
4P3855291–2014.08
AZQS140_Y1
a
c
d
e
f
g
Y1S
X1M
M1C
M2F M1F
Y1E
S1PH
a Heatexchanger
b Checkvalve(onlyforAZQS100andAZQS125)
c Internalserviceport
d Stopvalvewithserviceport(liquid)
e Stopvalvewithserviceport(gas)
f Accumulator
g Compressoraccumulator
M1C Motor(compressor)
M1F Motor(upperfan)
M2F Motor(lowerfan)
S1PH Highpressureswitch
X1M Terminal(communicationandpowersupply)
Y1E Electronicexpansionvalve
Y1S Solenoidvalve(4wayvalve)
AZQS100+125_Y1
d
e
f
g
S1PH
X1M
M1C
M1F
Y1E
c b a
Y1S
