12Technicaldata
Installerreferenceguide
40
AZQS100~140B8V1B+AZQS100~140B7Y1B
Splitsystemairconditioners
4P3855291–2014.08
AZQS100_Y1 AZQS125_Y1 AZQS140_Y1
Liquid Quantity 1
Type Flareconnection
Diameter(OD) Ø9.52mm
Gas Quantity 1
Type Flareconnection
Diameter(OD) Ø15.9mm
Drain Quantity 5
Type Hole
Diameter(OD) Ø26mm
Pipinglength Minimum 5m
Maximum 50m
Equivalent 70m
Chargeless 30m
Additionalrefrigerantcharge See"Todeterminetheadditionalrefrigerantamount"
Maximumheightdifferencebetweenoutdoor
unitandindoorunit
30m
Maximuminterunitleveldifference 0.5m
Heatinsulation Bothliquidandgaspipes
Defrostmethod Reversecycle
Defrostcontrol Sensorforoutdoorheatexchangertemperature
Capacitycontrolmethod Invertercontrolled
Capacitycontrol
Cooling Minimum
Maximum
Heating Minimum
Maximum
Safetydevices Highpressureswitch/fanmotorthermalprotector/fuse
Standardaccessories 1installationmanual/2tiewraps
Electricalspecifications:AZQS_Y1
AZQS100_Y1 AZQS125_Y1 AZQS140_Y1
Powersupply
Name Y1
Phase 3N~
Frequency 50Hz
Voltage 380415V
Voltagerange Minimum 342V
Maximum 456V
Current
Nominalrunningcurrent
Startingcurrent
Z
max
CompliestoEN61000311
Maximumrunningcurrent
Recommendedfuses 16A 20A 25A
Wiringconnections
Forpowersupply See"Connectingtheelectricalwiring"
Forconnectionwithindoor
Powersupplyintake Outdoorunitonly
