11
• Control systems
• Individual control systems • ARC*/BRC*
BRC2E52A/ BRC3E52A - Simplified remote control for hotel applications
Dimensional drawing
(Unit: mm)
3D064037
• Remote control dimensions
• Installation method
Upper case
Upper outlet
Operation
lamp
(green)
Lower case
Upper center
outlet
Staple
note 2
Through hole
Switch box
(Field supply part)
Lower case portion
Switchboxforoneswitch
ex.) KJB111A (optional
accessory)
Switchboxfortwoswitch
ex.) KJB211A (optional
accessory)
Between remote
control and
control box
Lower case portion
Leftoutlet
oblong hole
oblong hole
Embedded cord (use switch box)
Embedded cord
Exposed cord
Code outlet hole
Condit
