• Control systems
• intelligent Touch Manager • ED721208
3.1. Intelligent Touch Manager
3. Specifications
3.1.1. Main specifications
Port Number Use
D III 1ch D III-NET (Up to 64 groups)
LAN 1ch Web Access (100BASE-TX)
RS485 1ch External I/O module (Di, Dio, Ai)
Di(Pi) 4ch
Emergency stop input (Di1)
Pulse input, contact signal input
plus ADP IF 1ch iTM plus adaptor (Up to 7 adaptors)
internal modem
(option
1ch
Air Conditioning Network
Service System
POWER SUPPLY: DCM601A51 AC100-240V(± 10%)(50/60Hz)
INPUT: 23W
MASS: 2.4kg
FUSE AMP: 3.15A
Operatingtemperaturelimit:-0°C-+40°C
Operating humidity limit: MAX. 15°C - 85%
Storagetemperaturerange:-15°C-+60°C
Installation direction: Vertical direction only
