2.2. Options
57
• Control systems
• Management control • DCM601A51 •
Category Function Remarks
Basicfunctions
intelligent Touch Manager (DCM601A51) Maximumnumberofunits:5
Management points
Maximumnumberofmanagementpoints:3.250
(NumberofDIIIconnectionmanagementpoints:2.560)
Areas
Maximumnumberofareas:3.250
Maximum area hierarchies: 10
Supported languages
English, French, German, Italian, Spanish, Portuguese, Dutch, Chinese, and
Japanese
■ Types of management points and target equipment/interface
Management point Supported equipment Number of management points
Indoor
DIII-compatible indoor units
Maximum: 512 *
1
InterfaceadapterforSkyAir(DTA102A52)
Interfaceadapterforresidentialindoorunit(KRP928BB2S)
Central control adapter kit (DTA107A55)
AHU connection kit (EKEQMCB, EKEQDCB, EKEQFCB)
Biddle Air curtain (CYVS-DK - *BN/*SN, CYVM-DK-*BN/*SN, CYVL-DK-*BN/*SN)
Fan coil units (FWC-BT/BF, FWF-BT/BF)
Hot water hydrobox
DIII-compatible units (HXY-A, HXHD-A, EKHBRD-ACV1, EKHBRD-ACY1,
EKHVMRD-A, EKHVMYD-A)
Maximum: 512 *
1
Outdoor VRV outdoor units Maximum: 80
Ventilator Heat Reclaim Ventilator Maximum: 512 *
1
McQuay AHU POL638.0 BACnet connection Maximum: 512 *
6
D3 Chiller
DIII-compatible air-cooled chillers (UWA/Y) / water-cooled chillers (ZUW)
Maximum: 320 *
2
DIII-compatible inverter chillers (EWAQ-BAWN/BAWP, EWAQ-ADVP/ACV3/ACW1,
EWYQ-BAWN/BAWP, EWYQ-ADVP/ACV3/ACW1)
Di
Diportofintelligent Touch Manager
Maximum: 32 *
3
DiportofiTM plus adapter
D3 Di DIII Di Unit (DEC101A51) Maximum: 512 *
1
External Di Wago Di Maximum: 512 *
4
D3 Dio
D III Dio unit (DEC102A51) Maximum: 512 *
3
General-purpose adaptor (DTA103A51)
Maximum: 512 *
4
External Dio Wago Di, Do
Pi
Piportofintelligent Touch Manager Maximum: 32 *
3
PiportofiTM plus adapter
Maximum: 80
Internal Pi EnergyconsumptionofVRVoutdoorunits
External Ai Wago Di Maximum: 512 *
4
Internal Ai
Room temperature, setpoint
D3 Chiller outlet/inlet water temperatures
Maximum: 512 *
4
External PI WAGO Pi Maximum: 512 *
4
Externa Ao Wago Ao Maximum: 512 *
4
BACnet Di BACnet connection Maximum: 512 *
6
BACnet Dio BACnet connection Maximum: 512 *
6
BACnet Ai BACnet connection Maximum: 512 *
6
BACnet Ao BACnet connection Maximum: 512 *
6
BACnet MSi BACnet connection Maximum: 512 *
6
BACnet MSio BACnet connection Maximum: 512 *
6
*1:TotalofDIIIconnectionequipment(Indoor,Ventilator,D3Chiller,D3Di,D3Dio)
*2:MaximumnumerofmanagementpointsforD3Chilleronly
*3:TotalofDi/Pimanagementpoints
*4:TotalofExternalDi,ExternalDo,ExternalAiandInternalAi
*5:MaximumnumberofMcQuayAHUmanagementpoints.
*6:TotalofBACnetconnectionmanagementpoints.McQuayAHUmanagementpointsshouldbecountedas20permanagementpoint.
