3. System layout
3.1 Typical layout for indoor models with standard S21 connector integrated.
3.2 Typical layout for indoor models without S21 connector
14
• Control systems
• Individual control systems • BRC073
Required wireharness option available
in different lengths (BRCW901A03/08)
Required wireharness option available
in different lengths (BRCW901A03/08)
Adapter
KRP980*
S2
1
S21
indoor
indoor (n° S21)
Adapter
BRC073A1
Adapter
BRC073A1
BRC073A
1
BRC073A
1
