System overview
This intelligent Touch Controller is capable of controlling/monitoring up to 64 groups of indoor units (hereafter “groups”).
The main functions of the intelligent Touch Controller include:
1 Set back function, enabling a building’s temperature to be monitored and managed during both heating and cooling seasons through
a single setting.
2 Free cooling function, reducing the air conditioning energy consumption by actively introducing fresh air into rooms.
3 Collective starting/stopping of operation of the indoor units connected to the intelligent Touch Controller.
4 Starting/stopping of operation, temperature setting, switching between temperature control modes and enabling/disabling of
operation with the hand-held remote control by zone or group .
5 Scheduling by zone or group .
6 Monitoring of the operation status by zone or group .
7 Display of the air conditioner operation history.
8 Compulsory contact stop input from the central monitoring panel (non-voltage, normally-open contact).
9 Power proportional distribution of the air conditioners. (With the optional software DCS002C51)
10 Control and Monitoring of air conditioner with personal computer by the Controller (with the optional software DCS004A51).
A group of indoor units include:
1 One indoor unit without a remote control.
2 One indoor unit controlled with one or two remote controls.
3 Up to 16 indoor units controlled with one or two remote controls.
• Zone control with the intelligent Touch Controller
• Zone control, which allows collective settings for more than one group, is available with the intelligent Touch Controller, which
facilitates the setting operations.
• One setting makes the same setting for all of the units in one zone.
• Up to 128 zones can be set with one intelligent Touch Controller. (The maximum number of groups in one zone is 64.)
• Groups can be zoned at will with the intelligent Touch Controller.
• Units in one group can be divided into more than one zone.
44
