Part Names - Connection
Back
LINE
CO
ML
0DilPi3 COMPi2 Pi1F2F
1N
L
PHONE
RS-232C LAN
100 - 240V
45
• Control systems
• Centralised control systems • DCS601C51 •
ModemconnectorforAir
Conditioning Network Service
system
RS232-CconnectorforDIII-NET
Plus adapter
Terminalblockforpowersupply
TerminalblockforDIII-NET
communication
Ethernetconnectorforweb
Terminalblockforwatthourmeterandforcestopinputofindoorunits
Earth terminal block
Connect to AC100-240V power supply.
Terminal size is M4.
Theterminalsizeoftheterminalblock
forcommunicationwithindoorunitsis
M3.5.
When monitoring and operating the
indoor units using the optional Web and
E-mailfunctionsoftwaresoldseparately,
connect to LAN via Ethernet cable.
This is used when distributing the power supply to indoor units using
optionalPowerProportionalDistributionsoftwaresoldseparatelyand
when stopping the indoor units compulsorily by contact input.
ThesizeofterminalblockisM3.5.
Securely connect the earth wire.
Terminal size is M4
Using DIII-NET Plus adapter being
sold as an accessory, you can
increasethenumberofindoorunits
to be controlled.
When using Air Conditioning
Network Service System service,
connect it to the telephone line.
