4.3 Outlook and dimensions
4.3.1 outlook
BRC073A1 wired user interface BRC073A1 adapter
4.3.2 dimensions
BRC073A1 user interface (mm)
BRC073A1 adapter (mm)
Operation
lamp
(green)
Upper case
5x7 Oblong hole
5x15 Oblong hole
Code outlet hole
Lower case
18
• Control systems
• Individual control systems • BRC073
• Remote control dimensions
