146
• Control systems
• Standard protocol interfaces • LonWorks Interface
Dimensional drawing
3D040973
F1 F2
NL
T2T1
L0
3 — M4
4 — M3.5
49.6
1681
13019 19
13019 19
2601
2469.75 4.25
R2,25
R2,25
4.5
4.5
8 - C3
9
13
DMS504B51
Notes
1 Rated electrical conditions:
Rated voltage and frequency: single phase
AC100~240V 50/60Hz
Rated power: Maximu 5W
2 Conditions
Power Supply fluctuation: ±10% of the rated
value
Ambient temperature: -10~+50°C
Ambient humidity: 0~95% (Sweating is not
acceptable)
Preservation: -20~+60°C
3 Performance Insulation resistance: 50MW or
more by DC500 megohmeter
4 Weight: 1.5 kg
Detaileddrawingoffixinghole
Alive/wink
Service
Service switch
100-240V
~
50/60Hz
Power
Manufacturer's
label
Makesurethepowersupplyisoffwhencarryingout
thefollowingworks:
1.Whentakingoffthefrontcover
2. When operating the connectors/switches on the PCB
Caution
