1.2 Combination Overview
Introduction In the tables in this section:
Q “2” stands for symmetrical twin combination.
Q “3” stands for symmetrical triple combination.
Q “4“ stands for symmetrical double twin combination.
Q “P” stands for pair combination
Q ‘’M’’ stands for multi combination
Q ‘’T’’ stands for assymmetrical twin or triple combination
Pair split outdoor The table below contains the possible combinations between indoor units and pair split outdoor units.
Non Inverter
Inverter
Cooling Only Cooling Only Heat Pump
RS50BVMB RS60BVMB RKS25BVMB RKS35BVMB RKS50BVMB(9) RKS60BVMB(9) RKS25D(2)VMB RKS35D(2)VMB RXS25BVMB RXS35BVMB RSX50BVMB RSX60BVMB RXS25D(2)VMB RXS35D(2)VMB
950x950
cassette
standard
FCQ35B7V1 PPPP
FCQ50B7V1 PP P
FCQ60B7V1 PP P
600X600 cassette
FFQ25B(7)V1B PPPP
FFQ35B(7)V1B PPPP
FFQ50B(7)V1B PP P
FFQ60B(7)V1B PP P
duct
standard
FBQ35B7V1 PPPP
FBQ50B7V1 PP P
FBQ60B7V1 PP P
ceiling
suspended
FHQ35BUV1B PPPP
FHQ50BUV1B PP P
FHQ60BUV1B PP P
