ESIE05-04 Switch Box Layout
Part 1 – System Outline 1–103
3
1
4
5
5.9 FUQ71, 100, 125B
The illustration below shows the switch box layout:
C1R
PCB
T1R
X1MX2M
Item Description
PCB Printed circuit board
T1R Transformer
C1R Fan motor capacitor
X1M Terminal strip (for remote control P1/P2)
X2M Terminal strip (interconnection wiring)
