5.2.2 Rotary switch setting: DHW Install
1x Hot Water
Hyst HP
Timer BOH
5 x Parameter Overview
Daikin RoCon HP
Daikin Controller
008.1420844_13 – 02/2016
Operating instructions
39
Tab. 5-3 Parameter in rotary switch setting "DHW Install"
5.2.3 Rotary switch setting: Operating Mode
Standby
Reducing
Heating
Cooling
Summer
Automatic 1
Automatic 2
Tab. 5-4 Parameter in rotary switch setting "Operating Mode"
5.2.4 Rotary switch setting: Set Temp Day
T-Room 1 Setpoint
T-Room 2 Setpoint
T-Room 3 Setpoint
Tab. 5-5 Parameter in rotary switch setting "Set Temp Day"
5.2.5 Rotary switch setting: Set Temp Night
T-Reduced
T-Absence
Tab. 5-6 Parameter in rotary switch setting "Set Temp Night"
5.2.6 Rotary switch setting: DHW Set Temp
T-DHW Setpoint 1
T-DHW Setpoint 2
T-DHW Setpoint 3
Tab. 5-7 Parameter in rotary switch setting "DHW Set Temp"
5.2.7 Rotary switch setting: Time Program
Party
Away HC Program 2
Vacation DHW Program 1
Holiday DHW Program 2
HC Program 1 Circulation Time
Tab. 5-8 Parameter in rotary switch setting "Time Program"
5.2.8 Rotary switch setting: Remote Param
Bus - Scan
No selection
Contr BM1/BE1 #X
Mix Valve #X
Tab. 5-9 Parameter in rotary switch setting "Remote Param"
5.2.9 Rotary switch setting: Info
Overview Mode: Pump:
Ext: EHS:
Water Pressure
RT: BPV:
T-HS TV: tDHW:
TVBH: TA:
T-HS Setpoint
TR: V:
T-Outside TVBH2: Tliq2:
TR2 tA2:
T-DHW
Tdhw2: quiet:
T-DHW Setpoint
(see also chapter 3,

fig. 3-5)T-Return
Flow Rate
T-HC Qsc
T-HC Setpoint Qch
Status HS pump QWP
Runtime Compressor Qdhw
Runtime Pump HS type
Mixer Position Sw Nr B1/U1
Qboh Sw Nr Controller
Qchhp Sw Nr RTX RT
Tab. 5-10 Parameter in rotary switch setting "Info"
5.2.10 Exit button: Sonderfunktion
Manual Operation
FA failure
Protocol
Delete message
RoCon B1/U1 Reset
Parameter Reset
Timeprog Reset
Return
Tab. 5-11 Parameter in the level "Sonderfunktion"
5.3 Parameter levels for the EHS157068
mixer module
5.3.1 Rotary switch setting: Info
see section 5.2.9
5.3.2 Rotary switch setting: Operating
Mode
see section 5.2.3
5.3.3 Rotary switch setting: Set Temp Day
see section 5.2.4
5.3.4 Rotary switch setting: Set Temp Night
see section 5.2.5
5.3.5 Rotary switch setting: DHW Set Temp
No function
5.3.6 Rotary switch setting: DHW Install
No function
