6 x Parameter settings
Daikin RoCon HP
Daikin Controller
008.1420844_13 – 02/2016
Operating instructions
45
6.2.2 Level "System "
Parameter Description Access Setting range
Min / Max
Factory
setting
Increment
BE HF
Power DHW Heating output of electric auxiliary heater for hot water generation N E 1000 -
4
0000 W
3000 W 1000 W
BUH s1 power Heat capacity of the ancillary electric heater in Stage 1 heating support
see operating instructions of immersion heater BUxx.
N E - - -
BUH s2 power Heat capacity of the ancillary electric heater in Stage 2 heating support
see operating instructions of immersion heater BUxx.
N E - - -
Power BIV Setting limits the output of the heating support. N E 3000 -
4
0000 W
15000 W 1000 W
TDiff-DHW CH Only when parameter [HZU] = On.
Heating support activated when
Tdhw > T
HZUmin
+ 4 K and Tdhw > [T-HS Setpoint] + 1 K.
Heating support deactivated when
Tdhw < T
HZUmin
or Tdhw < [T-HS Setpoint].
T
HZUmin
= current active target hot water temperature [T-DHW Setpoint] + set parameter
value [TDiff-DHW CH ].
Tdhw = current hot water storage tank temperature
[T-HS Setpoint] = current active inflow target temperature (see tab. 6-12 and section 3.6.4)
N E 2 - 15 5 1
T vbh1 max Setting limits the inflow temperature (measured at t
V, BH
) with active heating support func-
tion.
N E 5 - 85°C 60 °C 1 °C
Equilibrium Temp Setting affects the operation of the potential-f
ree AUX switching contact (toggle switch out-
put A) defined in the parameter [AUX Fct].
Only when parameter [Equilibrium Func.] = On.
Outdoor temperature from which the optional ancillary heating is activated for supporting
t
he room heating. The bivalent temperature is relevant for operation of the optional ancillary
heater based on a backup demand (room heating operation). The temperature of the sen-
sor integrated into the external unit for heat pump (info value TA2) is used.
The info value TA2 displayed can differ from the value in the standard display depending
o
n parameter [Outside Config].
E E -15 °C to
+35 °C
0 °C 1 °C
Quite Mode Mode for low-noise operation with reduced output (see section 3.4.10).
0: Deactivated
1: Activated
2: Operated in whisper mode only at night between 22:00 and 6:00 hours.
E E 0 - 2 0 -
AUX Fct Setting assigns the switching conditions to the potential-free AUX contact (toggle switch
o
utput A; see section 3.6.9).
0: Function deactivated
AUX switching contact changes;
1: When storage tank temperature (Tdhw) ≥ value of parameter [T-DHW 1 min].
2: When there is a cooling or heating demand.
3: When there is a hot water demand to the Backup Heater (EKBUxx) or the configured
B
ackup Heater is required for heating support.
4: When there is a malfunction.
5: When sensor value (TVBH) > 60°C.
6: When the outdoor temperature < parameter value [Equilibrium Temp].
→ Hea
t pump continues to operate = parallel bivalence operation.
7: When the outdoor temperature < parameter value [Equilibrium Temp] + there is a heating
o
r hot water demand.
→ Hea
t pump does not continue to operate = alternative bivalence operation.
8: When there is a hot water demand.
9: When outside temperature < parameter value [Equilibrium Temp] + heat demand "Room
h
eating" (not for hot water demand). Heat pump no longer operates in room heating mode
below the value set in parameter [Equilibrium Temp] - only in hot water mode.
Use: An alternative bivalency operation room heating, if the boiler is incorporated hydrauli-
cally in such a way that it heats the depressurised storage tank water in the Daikin
A
ltherma EHS(X/H) directly (connectio
n via solar connections).
10: "Multi-Oil" - if outside temperature < parameter value [Equilibrium Temp] + heat demand
"
Room heating" (not for hot water demand). Heat pump no longer operates in room heating
mode below the value set in parameter [Equilibrium Temp] - only in hot water mode.
Use: An alternative bivalency operation room heating, if the boiler is hydraulically incorpo-
rated in the flow of the heat pump. For this type
of application, the frost protection function
must be deactivated on the Daikin Altherma EHS(X/H) (parameter [T-Frost Protect] = Off).
N E 0 - 9 0 1
AUX time AUX switching contact (A) switches with a delay whe
n the switching condition (see param-
eter [AUX Fct]) is pending for longer than the set time.
N E 0 - 600 s 120 s 5 s
T-DHW 1 min Switching threshold storage tank temperature (
Tdhw) for AUX switching contact (see pa-
rameter [AUX Fct]).
N E 20 - 85°C 50 °C 1 °C
Delta-T CH Set outdoor temperature spread The Daikin Altherma EHS(X/H) heating circulation pump
con
trols the flow rate in order to achieve the set spread between the inflow target tempera-
ture and the return flow temperature (t
V, BH
- t
R1
).
N E 2 - 20 K 7 K 1 K
V var Current minimum necessary volume flow in the system (calculated value, not configurable) N S INFO VALUE XXX -
T-Flow CH adj Only when parameter [Interlink fct] = On.
With a closed cooling RT switching contact
, the inflow target temperature is increased
by the set value (see tab. 6-1, parameter [Interlink fct]). Demand, e.g. from
FWXV(15/20)AVEB.
N E 0 - 50 K 5 K 1 K
