Daikin RoCon HP - Rotary Switch Setting: Time Program

Operating instructions
50
Daikin RoCon HP
Daikin Controller
008.1420844_13 – 02/2016
6 x Parameter settings
6.8 Rotary switch setting: Time Program
Parameter Designation Access Setting range
Min / Max
Factory
setting
Increment
BE HF
Party The heating circuit operates at the target room temperature set in the [T-Room 1 Setpoint]
parame
ter for the set period of time. If the [Automatic 1] or [Automatic 2] timer programmes
are active, the heating cycle is extended or started early. (Target room temperature - see
section 3.4.7).
The hot water generation is not affected.
E E 00:00 - 06:00 00:00 1 h
Away The heating circuit operates at the target room temperature set in the [T-Absence] parameter
for
the set period of time.
The hot water generation is not affected.
E E 00:00 - 06:00 00:00 1 h
Vacation The heating circuit operates at the target room temperature set in the [T-Absence] parameter
perman
ently (24 h per day).
A calendar function can be used to enter a time
period for the absence.
E E Date on first
da
y
-
Date on last
da
y:
- 1 Day
Holiday A calendar function can be used to enter a time period for presence.
During this time, the system operates exclusivel
y in accordance with the "Sunday" settings
in [DHW Program 1] and [HC Program 1].
E E Date on first
da
y
-
Date on last
da
y:
- 1 Day
HC Program 1 In this menu we can parametrise the 1st. timer programme for the heating circuit. 3 switching
cycles wit
h a resolution of 15 minutes can be set. A separate entry for each weekday is pos-
sible. Format: (On) hh:mm - hh:mm (Off)
Also, the cycles can be parametrised from Monday to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E see
chap
ter 3.4.7
see
tab. 3-9
15 min
HC Program 2 In this menu we can parametrise the 2nd. timer programme for the heating circuit. 3 switch-
ing cycles with a resolution of 15 minutes can b
e set. A separate entry for each weekday is
possible. Format: (On) hh:mm - hh:mm (Off)
Also, the cycles can be parametrised from Monday to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E see
chap
ter 3.4.7
see
tab. 3-9
15 min
DHW Program 1 In this menu we can parametrise the 1st. timer programme for hot water generation. 3 switch-
ing cycles with a resolution of 15 minutes can b
e set. A separate entry for each weekday is
possible. Format: (On) hh:mm - hh:mm (Off)
Also, the cycles can be parametrised from Monday to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E see
chap
ter 3.4.7
see
tab. 3-9
15 min
DHW Program 2 In this menu we can parametrise the 2nd. timer programme for hot water generation. 
3 switching cycles with a resolution of 15 minut
es can be set. A separate entry for each
weekday is possible. Format: (On) hh:mm - hh:mm (Off)
Also, the cycles can be parametrised from Monday to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E see
chap
ter 3.4.7
see
tab. 3-9
15 min
Circulation Time In this menu we can parametrise a timer programme for the circulation pump. 3 switching
cycles wit
h a resolution of 15 minutes can be set. A separate entry for each weekday is pos-
sible. Format: (On) hh:mm - hh:mm (Off)
Also, the cycles can be parametrised from Monday to Friday, Saturday to Sunday and Mon-
day to Sunday.
E E see
chap
ter 3.4.7
see
tab. 3-9
15 min
Tab. 6-10 Parameter in rotary switch setting "Time Program"
6.9 Rotary switch setting: Remote Param
Parameter Description Access Setting range
Min / Max
Factory
setting
Increment
BE HF
Bus - Scan Off: No function
On: Controller checks which RoCon devices are connect
ed to the system using the CAN bus
lines. Devices that are detected are displayed with their type and device ID (see chapter 4.1,
example: MM#8 = Mixer module with device ID 8).
The selection and confirmation of a device with the rotary switch (brief pressing of the button
places a
check mark in the selection box) activates the terminal function.
→ T
he control unit then operates as a remote control for the selected device 
(see chapter 3.4.9).
E E Off
On
Off -
No selection Activation switches to the local device. E E
-
Contr BM1/BE1 #X Activation switches to the Daikin Altherma EHS(X/H) with the device ID X (see section 6.12,
parameter [BUS ID HS]).
E E
-
Mix Valve #X Activation switches to the mixer module
with the device ID X (see section 6.13.1, parameter
[HC Assignment]).
E E -
Tab. 6-11 Parameter in rotary switch setting "Remote Param"
