3.3 Technical Parameters
Convention
Parameter
Supply voltage and frequency
100-120VAC,60Hz or 220-240VAC,50/60Hz
Main fuse
/
Power consumption
1200VA
Operating temperature range
+10°C to +40°C
Transport temperature range
-20°C to +50°C
Storage temperature range
+5°C to +50°C
Relative humidity for transport and storage
10% to maximum 85%, non-condensing
GB 4793.1 classification
Pollution level 2
Over-pressure category II
Operating altitude
Up to 2,500m above sea level
A weighted noise level
＜ 70 dB (A)
Size and weight
Parameter
Size, without packaging (width × depth ×
height), unit: mm
620 x 640 x 1170mm,±5%
Empty weight, without packaging
Approx. 180kg
Weight with packaging
Approx. 249kg
Dehydration cylinder
Parameter
Capacity
Up to 300 cassettes
Temperature (paraffin)
50°C - 65°C
Temperature (dehydration reagent)
Ambient temperature to 65°C
Temperature (rinse reagent)
60°C for alcohol; 65°C for xylene
Liquid level sensor
3 ultrasonic liquid level sensors
Concentration detection
1 concentration detection sensor
Cylinder lid lock
Automatic opening and closing of motor-driven
lock
Cylinder lid heating
Ambient temperature to 70°C
Surface temperature of the cylinder lid
Lower than 45°C
Inner wall of the cylinder lid
Teflon plating
Paraffin cylinder
Parameter
Number of small paraffin cylinders
3
Number of large paraffin cylinders
1
Capacity of small paraffin cylinders
4.2L
Capacity of large paraffin cylinders
5.6L
Paraffin melting temperature
50°C - 75°C
