1.7 Definitions, acronyms and abbreviations
Auxiliary battery Standard 12 V or 24 V vehicle battery.
AWG American Wire Gauge.
CAN Controller Area Network (communication protocol).
DC Direct Current.
EV Electric Vehicle.
HVIL Hazardous Voltage Interlock Loop
MCU Motor Control Unit.
TM4 ODIN TM4 diagnostic software.
VMU Vehicle Management Unit.
1.8 References
All system and product documentation is available in the Documentation section of the TM4 Extranet.
Requests to open an account can be made online via https://extranet.tm4.com.
Table 1 Related document references
Reference
Title/Description
Note
[1]
IN-8013e
MCU CAN Protocol vx.x Specifications
1, 2
[2]
IN-8013e
MCU J1939 CAN Protocol v1.1 Specifications
1
[3]
TG-0001
TM4 ODIN v4 Technical Guide
1
[4]
TG-xxxx
System Specifications
1, 2
[5]
TG-xxxx
Operations and Maintenance Guide
1, 2
[6]
Application Note
TM4 SUMO Fuse and DC Cable Selection
1
[7]
SC-6004E-007
TM4 Inverter Action Guide
1
[8]
INT3-0141
Interface drawing
1, 2
[9]
WE-xxxx
Cable end specifications
1, 2
[10]
WH-xxxx
Cable harness specifications
1, 2
[11]
Kit-0110
VMU connector harness kit
1
[12]
SC-6011E
Harness selection form
1
[13]
SC-6010E-001
Assembly instructions for TM4 Quick Connect Connectors
1
[14]
LV 123
Electrical testing standard. 2014-02
3
[15]
TM4 Extranet
https://extranet.tm4.com
-
Notes:
1. Refer to the latest published version of documentation and/or software package on the Extranet site.
2. Documentation specific to your system is available on the Extranet site.
3. External standard not supplied by TM4.
