Danfoss 102 User Manual

Mains supply 3 x 525-600 V AC Normal overload 110% for 1 minute
Size: P1K1 P1K5 P2K2 P3K0 P3K7 P4K0 P5K5 P7K5 P11K
Typical Shaft Output [kW] 1.1 1.5 2.2 3 3.7 4 5.5 7.5 11
IP20/Chassis A3 A3 A3 A3 A2 A3 A3 A3 B3
IP21/NEMA 1 A3 A3 A3 A3 A2 A3 A3 A3 B1
IP55/Type 12 A5 A5 A5 A5 A5 A5 A5 A5 B1
IP66/NEMA 4X A5 A5 A5 A5 A5 A5 A5 A5 B1
Output current
Continuous (3 x 525-550 V) [A] 2.6 2.9 4.1 5.2 - 6.4 9.5 11.5 19
Intermittent (3 x 525-550 V) [A] 2.9 3.2 4.5 5.7 - 7.0 10.5 12.7 21
Continuous (3 x 525-600 V) [A] 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0 18
Intermittent (3 x 525-600 V) [A] 2.6 3.0 4.3 5.4 - 6.7 9.9 12.1 20
Continuous kVA (525V AC) [kVA] 2.5 2.8 3.9 5.0 - 6.1 9.0 11.0 18.1
Continuous kVA (575V AC) [kVA] 2.4 2.7 3.9 4.9 - 6.1 9.0 11.0 17.9
Max. input current
Continuous (3 x 525-600 V) [A] 2.4 2.7 4.1 5.2 - 5.8 8.6 10.4 17.2
Intermittent (3 x 525-600 V) [A] 2.7 3.0 4.5 5.7 - 6.4 9.5 11.5 19
Additional specifications
Estim. power loss at rated max. load [W]
4)
50 65 92 122 - 145 195 261 300
IP20 max. cable cross-section (mains, motor, brake and
load
sharing) [mm
2
]/[AWG]
4,
4, 4 (12, 12, 12)
(min. 0.2 (24))
IP55,
IP66 max. cable cross-section (mains, motor, brake
and load sharing)
[mm
2
]/[AWG]
4, 4, 4 (12, 12, 12)
(min. 0.2 (24))
Max.
cable cross-section with disconnect 6, 4, 4 (12, 12, 12)
Mains disconnect switch included: 4/12
Weight IP20 [kg] 6.5 6.5 6.5 6.5 - 6.5 6.6 6.6 12
Weight IP21/55 [kg] 13.5 13.5 13.5 13.5 13.5 13.5 14.2 14.2 23
Efficiency
4)
0.97 0.97 0.97 0.97 - 0.97 0.97 0.97 0.98
Table 10.7
5)
With brake and
load sharing 95 / 4/0
Specifications
VLT
®
HVAC Drive Operating Instructions
72 MG11AI02 - VLT
®
is a registered Danfoss trademark
1010
