10.2 General Technical Data
Mains supply
Supply Terminals L1, L2, L3
Supply voltage 200-240 V ±10%
Supply voltage 380-480 V/525-600 V ±10%
Supply voltage 525-690 V ±10%
Mains voltage low/mains drop-out:
During low mains voltage or a mains drop-out, the FC continues until the intermediate circuit voltage drops below the minimum
stop level, which corresponds typically to 15% below the frequency converter's lowest rated supply voltage. Power-up and full
torque cannot be expected at mains voltage lower than 10% below the frequency converter's lowest rated supply voltage.
Supply frequency 50/60 Hz ±5%
Max. imbalance temporary between mains phases 3.0 % of rated supply voltage
True Power Factor (λ) ≥ 0.9 nominal at rated load
Displacement Power Factor (cos ϕ) near unity (>
0.98)
Switching on input supply L1, L2, L3 (power-ups) ≤ 7.5 kW maximum 2
times/min.
Switching on input supply L1, L2, L3 (power-ups) 11-75 kW maximum 1 time/min.
Switching on input supply L1, L2, L3 (power-ups) ≥ 90 kW maximum 1
time/2 min.
Environment according to EN60664-1 overvoltage category III/pollution degree 2
The unit is suitable for use on a circuit capable of delivering not more than 100,000 RMS symmetrical Amperes, 240/500/600/690
V maximum.
Motor output
(U, V, W)
Output voltage 0 - 100% of supply voltage
Output frequency (1.1-90 kW) 0-590 Hz
Output frequency (110-250 kW) 0-590
1)
Hz
Switching on output Unlimited
Ramp times 1-3600 s
1)
Voltage and power
dependent
Torque characteristics
Starting torque (Constant torque) maximum 110% for 60 s
1)
Starting torque maximum 135% up to 0.5 s
1)
Overload torque (Constant torque) maximum 110% for 60 s
1)
Starting torque (Variable torque) maximum 110% for 60 s
1)
Overload torque (Variable torque) maximum 110% for 60 s
Torque rise time in VVC
plus
(independent of fsw) 10
ms
1)
Percentage relates to
the nominal torque.
2)
The torque response time depends on application and load but as a general rule, the torque step from 0 to reference is 4-5 x
torque rise time.
Cable lengths and cross sections for control cables
1)
Max. motor cable length, screened 150 m
Max. motor cable length, unscreened 300 m
Maximum cross section to control terminals, flexible/ rigid wire without cable end sleeves 1.5 mm
2
/16 AWG
Maximum cross section to control terminals, flexible wire with cable end sleeves 1 mm
2
/18 AWG
Maximum cross section to control terminals, flexible wire with cable end sleeves with collar 0.5 mm
2
/20 AWG
Minimum cross section to control terminals 0.25 mm
2
/24AWG
1)
For power cables,
see electrical data tables.
Specifications
VLT
®
HVAC Drive Operating Instructions
MG11AI02 - VLT
®
is a registered Danfoss trademark
77
10 10
