Recommended max. fuse
Bussmann Bussmann Bussmann Bussmann Bussmann Bussmann
[kW] Type RK1 Type J Type T Type CC Type CC Type CC
1.1 KTS-R-5 JKS-5 JJS-6 FNQ-R-5 KTK-R-5 LP-CC-5
1.5-2.2 KTS-R10 JKS-10 JJS-10 FNQ-R-10 KTK-R-10 LP-CC-10
3 KTS-R-15 JKS-15 JJS-15 FNQ-R-15 KTK-R-15 LP-CC-15
4 KTS-R-20 JKS-20 JJS-20 FNQ-R-20 KTK-R-20 LP-CC-20
5.5 KTS-R25 JKS-25 JJS-25 FNQ-R-25 KTK-R-25 LP-CC-25
7.5 KTS-R-30 JKS-30 JJS-30 FNQ-R-30 KTK-R-30 LP-CC-30
11-15 KTS-R-35 JKS-35 JJS-35
18 KTS-R-45 JKS-45 JJS-45
22 KTS-R50 JKS-50 JJS-50
30 KTS-R-60 JKS-60 JJS-60
37 KTS-R-80 JKS-80 JJS-80
45 KTS-R-100 JKS-100 JJS-100
55 KTS-R125 JKS-125 JJS-125
75 KTS-R150 JKS-150 JJS-150
90 KTS-R175 JKS-175 JJS-175
Table 10.15 525-600 V, Frame Sizes A, B and C
Recommended max. fuse
SIBA Littel fuse Ferraz-Shawmut Ferraz-Shawmut
[kW] Type RK1 Type RK1 Type RK1 Type J
0.37-1.1 5017906-005 KLSR005 A6K-5R HSJ6
1.5-2.2 5017906-010 KLSR010 A6K-10R HSJ10
3 5017906-016 KLSR015 A6K-15R HSJ15
4 5017906-020 KLSR020 A6K-20R HSJ20
5.5 5017906-025 KLSR25 A6K-25R HSJ25
7.5 5017906-030 KLSR030 A6K-30R HSJ30
11-15 5014006-040 KLSR035 A6K-35R HSJ35
18 5014006-050 KLSR045 A6K-45R HSJ45
22 5014006-050 KLS-R50 A6K-50R HSJ50
30 5014006-063 KLSR060 A6K-60R HSJ60
37 5014006-080 KLSR075 A6K-80R HSJ80
45 5014006-100 KLSR100 A6K-100R HSJ100
55 2028220-125 KLS-125 A6K-125R HSJ125
75 2028220-150 KLS-150 A6K-150R HSJ150
90 2028220-200 KLS-175 A6K-175R HSJ175
Table 10.16 525-600 V, Frame Sizes A, B and C
Specifications
VLT
®
HVAC Drive Operating Instructions
MG11AI02 - VLT
®
is a registered Danfoss trademark
85
