Gauge information
M4 Servo supply pressure maximum angle 600 bar [10,000 psi]
9/16-18 O-ring fitting
M5 Servo supply pressure 600 bar [10,000 psi]
9/16-18 O-ring fitting
Series 51-1 motors
Guage port M4
Servo pressure
maximum angle
Loop flushing
shuttle valve
Charge pressure
relief valve
Main ports A+B
Case drain L1
Alternate
position
case drain L2
Side port
Sysem pressure B
Gauge port M2
System pressure A
Guage port M1
M4
B
A
X
Y
W
W
Y
P101 203E
System pressure A+B
Guage port M1+M2
Main port A
Main
port B
Axial port
B
A
M4
X
Y
Y
W
P107 758E
Gauge information
M1 System pressure port A 600 bar [10,000 psi]
9/16-18 O-ring fitting
M2 System pressure port B 600 bar [10,000 psi]
9/16-18 O-ring fitting
Service Manual
Series 51 and 51-1 Motors
Pressure measurements
24 |
©
Danfoss | March 2016 11008567 | AX00000013en-US0202
