Figure 4: AK-UI55 Info Figure 5: AK-UI55 Set Figure 6: AK-UI55 Bluetooth
AK-CC55 Single Coil and Single Coil UI
AK-CC55 Single Coil – Controlling one EEV valve.
An application mode setting will congure inputs and outputs for the desired use. There are nine applications to
choose from. Regulation is performed using an AKV expansion valve or an external stepper driver via Analogue
Output A01.
Standard enclosure. Typically used for display cases
where the controller is mounted in a tray.
The standard enclosure can be expanded with one or
two external displays.
AK-CC55 Single Coil UI
Single Coil controller with built-in display. Same functionalities as AK-CC55 Single Coil.
Enclosure with built-in setting display. Typically used
for cold rooms.
For controllers with built-in, only one external display
can be connected.
External display
There are three versions available with dierent functions:
• AK-UI55 Info: Temperature display.
• AK-UI55 Set: Temperature display with control buttons on the front.
• AK-UI55 Bluetooth: Temperature display with Bluetooth communication, for use with AK-CC55 Connect Mobile
app.
AK-CC55 Single Coil and Single Coil UI
© Danfoss | Climate Solutions | 2021.02 BC364229688105en-000101 | 8
