Page #57 background imageLoading...
Page #57 background image
Fan control
Table 36: Fan control
Function
Description
Values
Code
Short name
Control state A
Readout of the actual control state of the controller
0=Normal ctrl., 1=Hold after defrost, 2=Min ON timer,
3=Min OFF timer, 4=Drip o, 10=Main switch OFF,
11=Thermostat cut-out, 12=Frost protection S4,
13=Not_used, 14=Defrost, 15=Fan delay, 17=Door
open, 18=Melt period, 19=Modulating temp. control,
20=Emergency control, 23=Adaptive superheat con-
trol, 24=Start injection, 25=Manual control, 26=No re-
frigerant selected, 16=Forced closing, 29=Case clean-
ing, 30=Forced cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down controller,
48=Adaptive liquid control
u00
u00 Ctrl. state
Fan
Actual status of output function
0=OFF, 1=ON
u59
u59 Fan relay
Fan ECO
Actual status of output function
0=OFF, 1=ON
U37
U37 Fan Eco
Fan pulsing mode
Pulse operation of fan 0: No pulse operation 1: Pulse
operation when the thermostat is cut out2: Pulse op-
eration when the thermostat is cut out, but only dur-
ing night operation
0=No pulsing, 1=Pulsing cut-out, 2=Pulsing cut-out
night
F05
F05 FanPulseMode
Fan period time
Period time for pulsing of fan
F06
F06 Fan cycle
Fan ON cycle
ON time for fan. The ON period is set as a percentage
of the period time
F07
F07 Fan ON %
Fan stop high S5
temp.
Fan stop temperature The function stops the fans in
an error situation, so that they will not provide power
to the appliance. If the defrost sensor registers a high-
er temperature than the one set here, the fans will be
stopped. There will be re-start at 2 K below the set-
ting. The function is not active during a defrost or
start-up after a defrost.
F04
F04 FanStop temp
Fan at forced closing
You can set whether fans should be operational or
stopped if the function "Forced closing" is activated
here. 0: Fans are OFF1: Fans are ON2: Fans are OFF and
defrost is not permitted3: Fans are ON and defrost is
not permitted
0=OFF, 1=ON, 2=OFF and suppress defrost, 3=ON and
suppress defrost
o90
o90 Fan ForcedCl
Fan stop at blinds
closing
When blinds are closing the fans are stopped in the
dened time delay in order to ensure that the blinds
are closed correctly
P65
P65 BlindFanStop
Railheat control
Table 37: Railheat control
Function
Description
Values
Code
Short name
Control state A
Readout of the actual control state of the controller
0=Normal ctrl., 1=Hold after defrost, 2=Min ON timer,
3=Min OFF timer, 4=Drip o, 10=Main switch OFF,
11=Thermostat cut-out, 12=Frost protection S4,
13=Not_used, 14=Defrost, 15=Fan delay, 17=Door
open, 18=Melt period, 19=Modulating temp. control,
20=Emergency control, 23=Adaptive superheat con-
trol, 24=Start injection, 25=Manual control, 26=No re-
frigerant selected, 16=Forced closing, 29=Case clean-
ing, 30=Forced cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down controller,
48=Adaptive liquid control
u00
u00 Ctrl. state
Dewpoint
Actual dewpoint received from system manager via
network
x18
--- Dew point
Rail heat
Actual status of output function
0=OFF, 1=ON
u61
u61 Railh. relay
Rail heat power
Readout of the actual rail power in %
u85
u85 Rail DutyC %
Rail heat PWM
Actual status of output function
U59
U59 Railheat PWM
Rail heat control
mode
The rail heat can be controlled in several ways: 0: Rail
heat is running all the time 1: Pulse control is used
with a timer function following the day/night opera-
tion 2: Pulse control is used with a dewpoint function.
This function requires that a signal is received about
the dewpoint value. The value is measured by a sys-
tem manager and sent to the controller via the data
communication.
0=ON, 1=Day/Night timer, 2=Dewpoint ctrl.
o85
o85 Railh. mode
Rail heat ON cycle
day
Rail heat power during day time. The ON period is set
as a percentage of the period
o41
o41 Railh.ONday%
Rail heat ON cycle
night
Rail heat power during night time. The ON period is
set as a percentage of the period time
o42
o42 Railh.ONngt%
Rail heat period time
Period time for pulsing of rail heat
o43
o43 Railh.cycle
© Danfoss | Climate Solutions | 2021.02 BC364229688105en-000101 | 57
