Rail heat PWM - Peri-
od time
Period time for the pulse width modulation
Lowest permitted rail heat power. When the meas-
ured dewpoint is below the dened minimum limit
the rail heat will run with the set minimum power
If the measuered dewpoint is below the set value the
rail heat is running at minimum heat
If the measured dewpoint is above the set value the
rail heat is maximum
Light/Blinds/Cleaning control
Table 38: Light/Blinds/Cleaning control
Readout of the actual control state of the controller
0=Normal ctrl., 1=Hold after defrost, 2=Min ON timer,
3=Min OFF timer, 4=Drip o, 10=Main switch OFF,
11=Thermostat cut-out, 12=Frost protection S4,
13=Not_used, 14=Defrost, 15=Fan delay, 17=Door
open, 18=Melt period, 19=Modulating temp. control,
20=Emergency control, 23=Adaptive superheat con-
trol, 24=Start injection, 25=Manual control, 26=No re-
frigerant selected, 16=Forced closing, 29=Case clean-
ing, 30=Forced cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down controller,
48=Adaptive liquid control
Status of the day/night operation (night operation:
on/o)
Actual status of output function
Actual status of output function
Conguration of light function1: Light is controlled
via day/night status 2: Light is controlled via data
communication and master control parameter "MC
Light signal" 3: Light is controlled by door contact on
DI input. When the door is opened the relay will cut
in. When the door is closed again there will be a time
delay of two minutes before the light is switched o.
4: As "2" but if there are any 15-minute network er-
rors, the light will switch on and the night blind will
open. 5: Light is controlled via DI input signal
1=Day and night, 2=Network, 3=Door switch, 4=Net-
work (Fallback), 5=Digital input
Dene how light and blinds are to be controlled at
Main switch OFF 0: Light is switched o and night
blinds are open when the main switch is o 1: Light
and night blinds are independent of main switch.
Time delay from when blinds have been opened
manually until they close again
The status of the function can be seen here or the
function can be started manually.0 = Normal opera-
tion (no cleaning) 1 = Only fans are running to defrost
the evaporator. All other outputs are O. 2 = Cleaning
with stopped fans. All outputs are O. If the function
is controlled by a digital input signal, the relevant sta-
tus can be seen here in the menu.
0=OFF, 1=Fans run, 2=Cleaning
Display control
Table 39: Display control
Readout of the actual control state of the controller
0=Normal ctrl., 1=Hold after defrost, 2=Min ON timer,
3=Min OFF timer, 4=Drip o, 10=Main switch OFF,
11=Thermostat cut-out, 12=Frost protection S4,
13=Not_used, 14=Defrost, 15=Fan delay, 17=Door
open, 18=Melt period, 19=Modulating temp. control,
20=Emergency control, 23=Adaptive superheat con-
trol, 24=Start injection, 25=Manual control, 26=No re-
frigerant selected, 16=Forced closing, 29=Case clean-
ing, 30=Forced cooling, 31=Door open, 32=Power-up
delay, 33=Air heating, 45=Shut down controller,
48=Adaptive liquid control
Readout of the temperature shown on the display
Readout of the temperature shown on the display
Select which temperature to show in the display
1=Display air, 2=S6 Product temp.
AK-CC55 Single Coil and Single Coil UI
© Danfoss | Climate Solutions | 2021.02 BC364229688105en-000101 | 58
