Danfoss Ally User Manual

17
BC349733524454en-010401 © Danfoss | FEC | 2023.06 |
User Guide Danfoss Ally™ Radiator Thermostat
8. Display
8.1 Display Screen
Short press on and the display screen appears.
The Danfoss Ally™ Radiator Thermostat is displaying the set temperature, not the measured
room temperature.
8.2 Display Symbols:
Installation Mode must always be activated when installing or removing the Danfoss
Ally™ Radiator Thermostat. The thermostat may be irreparably damaged if not in the
correct position during installation.
Temperature is shown in degrees Celsius. The Danfoss Ally™ Radiator Thermostat is dis-
playing the set temperature, not the measured room temperature.
The antenna symbol flashes when you need to connect the app to the thermostat.
Low battery. The battery icon will flash on the display.
8.3 Display Rotation
The Danfoss Ally™ Radiator Thermostat can be mounted in a horizontal or vertical position, de-
pending on your radiator valve. You can set the display rotation to either ‘horizontal’ or ‘vertical’
within the Danfoss Ally™ Radiator Thermostat App under advanced settings.
8.4 Stand-alone Mode
Danfoss Ally™ Radiator Thermostat can also be used as a stand-alone thermostat without con-
nection to the app.
Functionality is reduced.
Use the handwheel to adjust the temperature. The display shows the required temperature and
not the room temperature. In manual mode, there are no comfort or setback temperatures or
times set.

Danfoss Ally Specifications

General

Accuracy	50 sec/month
Noise level	30 dB
Product color	White
Smart thermostat	Yes
Operating frequency	2400 MHz
Suitable for indoor use	-
Maximum water temperature	90 °C
Storage temperature (T-T)	-20 - 65 °C
Temperature control range	5 - 35 °C
Operating temperature (T-T)	0 - 40 °C
International Protection (IP) code	IP20
Package weight	250 g
Display type	LCD
Battery type	AA
Power consumption (typical)	1.2 W

Weight and Dimensions

Weight	198 g
Diameter	55 mm
